Kuri-Clamp™ Standard Duty Worm Gear Clamps

Item #: WGC-CS-SS-MAIN

From $11.40

Reset

Kuri-Clamp™ Standard Duty Worm Gear Clamps

Kuri-Clamp™ Standard Duty Worm Gear Clamps used in automotive, industrial and general purpose applications.

APPLICATIONS

  • Automotive
  • Industrial
  • General Purpose

CONSTRUCTION

  • WGC-CS Series: Four-piece construction consisting of a 1/2″ wide, 300 series stainless steel band; plated carbon steel hex screw with 5/16″ head and two-piece, 300 series stainless steel housing.
  • WGC-SS Series: Four-piece construction consisting of a 1/2″ wide, 300 series stainless steel band; stainless steel hex screw with 5/16″ head and two-piece, 300 series stainless steel housing.

FEATURES & BENEFITS

  • Quadra-Lock Housing Design with added saddle to eliminate risk of seam separation and virutally eliminating housing “lift and twist”
  • Evenly Distributed Radial Pressure quality controlled to military standard specifications eliminates leakage caused by uneven housings and provides higher sealing pressure with lower applied torque
  • Arched, Perforated Slots provides more overall steel between perforations for added band strength and allows for smoother engagement
  • 300 Series Stainless Steel Band provides durability and superior corrosion resistance
  • Hex screws with sharply defined hex angles for better gripping power and more threads per screw results in increased torque strength
  • Meets Industry Standards for SAE J1508 Type F and RoHS compliant
  • Torque installation rating of 25-37 inch pounds (WGC-CS) and 30-45 inch pounds (WGC-SS)

Additional information

Weight Please select an option above.
Clamp Range

⁷⁄₁₆" – ²⁵⁄₃₂" (box of 10)
½" – ²⁹⁄₃₂" (box of 10)
⁹⁄₁₆" – 1-¹⁄₁₆" (box of 10)
¹¹⁄₁₆" – 1-¼" (box of 10)
¹³⁄₁₆" – 1-½" (box of 10)
¹³⁄₁₆" – 1-¾" (box of 10)
1-¹⁄₁₆" – 2" (box of 10)
1-⁵⁄₁₆" – 2-¼" (box of 10)
1-⁹⁄₁₆" – 2-½" (box of 10)
1-¹³⁄₁₆" – 2-¾" (box of 10)
2-¹⁄₁₆" – 3" (box of 10)
2-⁵⁄₁₆" – 3-¼" (box of 10)
2-⁹⁄₁₆" – 3-½" (box of 10)
2-¹³⁄₁₆" – 3-¾" (box of 10)
3-¹⁄₁₆" – 4" (box of 10)
3-⁵⁄₁₆" – 4-¼" (box of 10)
3-⁹⁄₁₆" – 4-½" (box of 10)
1- ⅞" – 5" (box of 10)
2-½" – 5-½" (box of 10)
3-⅛" – 6" (box of 10)
3-⅝" – 6-½" (box of 10)
4-⅛" – 7" (box of 10)

Material

300 Stainless Steel Only
300 Stainless Steel & Carbon Steel Hex Screw

SKU WGC-CS06
SKU WGC-SS96
SKU WGC-CS08
SKU WGC-CS10
SKU WGC-CS12
SKU WGC-CS16
SKU WGC-CS20
SKU WGC-CS24
SKU WGC-CS28
SKU WGC-CS32
SKU WGC-CS36
SKU WGC-CS40
SKU WGC-CS44
SKU WGC-CS48
SKU WGC-CS52
SKU WGC-CS56
SKU WGC-CS60
SKU WGC-CS64
SKU WGC-CS72
SKU WGC-CS80
SKU WGC-CS88
SKU WGC-CS96
SKU WGC-CS104
SKU WGC-SS06
SKU WGC-SS08
SKU WGC-SS10
SKU WGC-SS12
SKU WGC-SS16
SKU WGC-SS20
SKU WGC-SS24
SKU WGC-SS28
SKU WGC-SS32
SKU WGC-SS36
SKU WGC-SS40
SKU WGC-SS44
SKU WGC-SS48
SKU WGC-SS52
SKU WGC-SS56
SKU WGC-SS60
SKU WGC-SS64
SKU WGC-SS72
SKU WGC-SS80
SKU WGC-SS88
SKU WGC-SS104
