Low range, food-grade solution for extreme low-temperature control without water or glycols
Paratherm LR heat transfer fluid is an aliphatic hydrocarbon-based heat transfer fluid designed for use in closed-loop, liquid phase heating and cooling systems up to a 450°F in electric and steam heaters and down to a -58°F surface temperature in direct-expansion exchangers. Registered HT-1 for incidental food contact by NSF.
FEATURES & BENEFITS
- Excellent low-temperature & dielectic properties
- Premium NSF HT-1 food-grade heat transfer fluid
- Efficient alternative to glycols & silicones
- Non-aromatic
- Non-aqueous
- Operating Temperature Range: -112°F (-80°C) to 450°F (232°C)
APPLICATIONS
- Specialty chemical processing
- Extraction sciences
- Food & beverage processing
- Pharmaceutical
REDUCE PROCESS HAZARDS WHEN PROCESSING WATER-SENSITIVE PRODUCT
Many products undergo a violent exothermic reaction when exposed to water. Paratherm LR low range heat transfer fluid can be used safely for temperature control in these reactions because, unlike water/glycols, it’s not mixed with water. And because it contains no double bonds or bonded oxygen molecules, it’s extremely stable.
WIDER TEMPERATURE RANGE THAN GLYCOLS
Paratherm LR low range heat transfer fluid has higher heat-transfer coefficients than 50% ethylene-glycol and 50% propylene-glycol solutions below -22°F and -4°F respectively. And while glycol solutions have a maximum operating temperature of 320°F, Paratherm LR is completely stable up to its 450°F maximum operating temperature. Stability tests showed less than 3% degradation after 500 hours at 550°F.
Contact us to learn more about Paratherm LR heat transfer fluid
